HIOKI L1021-02 - Black Patch Cord
Description
Product information HIOKI L1021-02 - Black Patch Cord
The HIOKI L1021-02 is a black patch cord for connecting and branching voltage cords such as the L9438 and L1000. For use with HIOKI Power Analysers and Power Quality Analysers, the cord features a 4 mm banana plug on one side and a stackable dual banana connector on the other side. It is designed for measurement categories CAT IV 600 V and CAT III 1000 V.
Technical Specifications
- Cable length: 500 mm ±50 mm
- Connectors: 4 mm banana plug to stackable dual banana connector
- Measurement category: CAT IV 600 V, CAT III 1000 V
- Colour: black
- Protective caps: both ends
Related Products
- L9438
- L1000
- PW8001
- PW6001
- PW4001
- PW3390
- PW3365
- PW3360
- PQ3198
- PQ3100
What's in the Box
- L1021-02 Black Patch Cord
Skip product gallery
Sale price:
€22.40
Regular price:
€28.00
Regular price:
€108.00
.jpg "HIOKI PW3390 - Portable 4-channel Power Analyzer")
Regular price:
€3,218.00
Regular price:
€4,888.00
Regular price:
€7,738.00
.jpg "PQ3198-94 - Power quality analyzer kit with 4 flexible current clamps")
Regular price:
€8,098.00
Related Products
20
L1021-01
L1021-01 - Red Patch Cord
The HIOKI L1021-01 is a red patch cord for connecting and branching voltage cords such as the L9438 and L1000. For use with HIOKI Power Analysers and Power Quality Analysers, the cord features a 4 mm banana plug on one side and a stackable dual banana connector on the other side. It is designed for measurement categories CAT IV 600 V and CAT III 1000 V.Technical Specifications Cable length: 500 mm ±50 mmConnectors: 4 mm banana plug to stackable dual banana connectorMeasurement category: CAT IV 600 V, CAT III 1000 V Colour: red Protective caps: both ends Related ProductsL9438 L1000PW8001 PW6001 PW4001PW3390PW3365PW3360PQ3198 PQ3100
L1000
HIOKI L1000 - Voltage Cord Set
The Voltage Cord Set L1000 is a voltage measurement accessory set consisting of leads and crocodile clips, adapted to the requirements of HIOKI power quality analysers and power analysers. It enables safe connection to measurement points and supports phase identification by colour coding. The set includes 3 m leads, one red, one yellow, one blue and one grey, as well as four black. These are equipped with 4 mm safety banana plugs and are used together with the colour-matched crocodile clips included in the set. With a maximum opening width of 33 mm, the crocodile clips are suitable for electrical conductors up to 25 mm in diameter. Typical applicationsVoltage measurement in power quality analysis Voltage measurement in multiphase systems Technical specifications Set contents: one red, one yellow, one blue, one grey and 4 black leads, each with matching crocodile clipLead: length 3 m (3000 mm), 4 mm safety banana plug Crocodile clip: colour coded, opening width 33 mm, for conductors up to Ø25 mm Measurement category: CAT III 600 V, CAT II 1000 VCompatible devicesPQ3198 PW3390 PW4001 PW8001 M7103
PW8001
HIOKI PW8001 - Modular 8-channel High Precision Power Analyzer
Modular high precision power analyzer, up to 8 channels, ±0.03% basic accuracy, 15 MHz
sampling rate, 18-bit A/D conversion, automatic phase shift correction for Hioki current
sensors, 1 ms data update rate, CMRR 110 dB @ 100 kHz
PW4001
HIOKI PW4001 - 4-channel Power Analyzer
Portable 4-channel power analyzer with ±0.04% basic accuracy, DC to 600 kHz frequency bandwidth, CAT II 1500 V DC, 1 ms data update rate, waveform & D/A output, motor analysis, external DC power input
PW3390
HIOKI PW3390 - Portable 4-channel Power Analyzer
Portable 4-channel Power Analyzer, ±0.09% basic accuracy, DC to 200 kHz measurement band for power, 16-bit conversion, phase shift correction for HIOKI current sensors, 50 ms data update rate, 16-ch waveform/analog output, motor analysis function, WLTP compliant
PW3365
HIOKI PW3365 - Compact Three-Phase Power Logger with non-contact voltage sensors
