HIOKI Precision Current Clamps with Zero-Flux Technology

Accurate current measurement with flexible clamp-on design

HIOKI precision current clamps enable accurate, non-intrusive AC and DC current measurement without interrupting the circuit. Across the portfolio, they support currents from milliampere levels up to 1000 A, bandwidths up to 2 MHz, and high measurement accuracy. Select the optimum current clamp for your application, for example the CT6746A Current Clamp for currents up to 1000 A or the CT6834 with an ultra-slim design for measurements in confined areas. All models are suitable for measurements on production-ready equipment in operation.

Precision current clamps are used where accuracy, ease of use, and minimal impact on the test setup are essential, including vehicle on-board measurements (incl. WLTP), power electronics testing, efficiency analysis, and measurements in hard-to-access environments.

CT6841A

CT6841A - AC/DC High-accuracy Current Clamp, 20 A / 2 MHz

AC/DC current clamp using advanced fluxgate technology, 20A rated current, basic accuracy ±0.2% rdg., wide temperature range of -40 °C to 85 °C, wide bandwidth from DC to 2 MHz, maximum conductor diameter 20 mm, cable length 3 m

€1,948.00*

View product

CT6834

CT6834 - Super-slim AC/DC high-accuracy Current Clamp, 500 A / 50 kHz

Ultra-slim AC/DC current clamp using advanced fluxgate technology, 500 A rated current, DC to 50 kHz frequency bandwidth, high accuracy ±0.07% rdg., wide temperature range of -40°C to +85°C, maximum conductor diameter 20 mm, cable length 5 m

€2,368.00*

View product

CT7822

HIOKI CT7822 - Ultra-compact AC/DC Current Probe, 20 A / 100 kHz

HIOKI CT6904A high-precision AC/DC current sensor with 500 A range and 4 MHz bandwidth for accurate measurements in power electronics and test environments. Order now from HIOKI Europe.

€1,338.00*

View product

CT6833

CT6833 - Super-slim AC/DC high-accuracy Current Clamp, 200 A / 50 kHz

Ultra-slim AC/DC current clamp using advanced fluxgate technology, 200 A rated current, DC to 50 kHz frequency bandwidth, high accuracy ±0.07% rdg., wide temperature range of -40°C to +85°C, maximum conductor diameter 20 mm, cable length 5 m

€2,288.00*

View product

CT6831

CT6831 - Ultra-compact AC/DC Current Probe, 20 A / 100 kHz

Ultra small zero flux clamp-on AC/DC Current Probe using flux gate detection, high accuracy ±0.3 % rdg., wide temperature range -40 to 85 oC, measurable current from 1 mAup to 20 A, ME15W connector

€1,628.00*

View product

CT6845A

CT6845A - AC/DC Current Clamp, Fluxgate, 500 A / 200 kHz

AC/DC current clamp using advanced fluxgate technology, 500A rated current, basic accuracy ±0.2% rdg., wide temperature range of -40 °C to 85 °C, bandwidth from DC to 200 kHz, maximum conductor diameter 50 mm, cable length 3 m

€2,128.00*

View product

CT7812

CT7812 - Ultra-compact AC/DC Current Probe, 2 A / 100 kHz

Ultra-small, zero-flux clamp-on AC/DC Current Probe using flux gate detection, high accuracy ±0.3 %, max. resolution 0.1 mA, wide temperature range -40 to 85 °C, measurable current up to 2 A, designed exclusively for LR8450 Series Data Logger

€1,338.00*

View product

CT6830

CT6830 - Ultra-compact AC/DC Current Probe, 2 A / 100 kHz

Ultra-small, zero-flux clamp-on AC/DC Current Probe using flux gate detection, high accuracy ±0.3 % rdg., wide temperature range -40 to 85 oC, measurable current from 100 µAup to 2 A, ME15W connector

€1,628.00*

View product

CT6846A

CT6846A - AC/DC High-accuracy Current Clamp, 1000 A / 100 kHz

AC/DC current clamp using advanced fluxgate technology, 1000A rated current, basic accuracy ±0.2% rdg., wide temperature range of -40 °C to 85 °C, bandwidth from DC to 100 kHz, maximum conductor diameter 50 mm, cable length 3 m

€2,498.00*

View product

CT6843A

CT6843A - AC/DC High-accuracy Current Clamp, 200 A / 700 kHz

AC/DC current clamp using advanced fluxgate technology, 200A rated current, basic accuracy ±0.2% rdg., wide temperature range of -40 °C to 85 °C, wide bandwidth from DC to 700 kHz, maximum conductor diameter 20 mm, cable length 3 m

€2,018.00*

View product

HIOKI Precision Current Clamp Sensor Overview

HIOKI’s AC/DC current clamps offer the perfect balance of ease of use and high-precision measurement, thanks to fluxgate-technology in a practical split-core design. Engineered for non-contact current measurement, these clamps enable fast, hassle-free deployment in both laboratory and field applications.

	Large Clamps up to 1 kA / 200 kHz		Precision Clamps up to 500 A / 2 MHz			NEW Compact Clamps up to 500 A / 50 kHz		Ultra-compact Sensors up to 20 A / 100 kHz
Model	CT6846A	CT6845A	CT6844A	CT6843A	CT6841A	CT6834	CT6833	CT6831	CT6830
Rated Current	±1000 A	±500 A	±500 A	±200 A	±20 A	±500 A	±200 A	±20 A	±2 A
Bandwidth	DC – 100 kHz	DC – 200 kHz	DC – 500 kHz	DC – 700 kHz	DC – 2 MHz	DC – 50 kHz		DC – 100 kHz
Basic Accuracy	±0.2% rdg					±0.07% rdg		±0.3% rdg
Output Voltage	2 mV/A	4 mV/A		10 mV/A	100 mV/A	4 mV/A	10 mV/A	100 mV/A	1 V/A
Max. Conductor Diameter	Ø 50 mm		Ø 20 mm					Ø 5 mm
