BT6065 - precision battery tester and 6.5 digit voltmeter

Precision Battery Tester for simultaneous internal resistance (AC-IR) and open circuit voltage (OCV) measurements, 6.5-digit resolution and two ranges for OCV (10 V and 100 V), 5.5- digit resolution and 5 ranges for AC-IR at 1 kHz, fully remote-controllable via LAN, RS-232C, USB, and External I/O.

€4,528.00*

Content: 1 Each

*Prices excl. VAT plus shipping costs

In stock in Germany

Available stock: 1

Product details

Product number: BT6065

EAN: 4536036015047

Length: 355 mm

Width: 430 mm

Height: 180 mm

Weight: 3.8 kg

Product information BT6065 - precision battery tester and 6.5 digit voltmeter

Banner Specs

OCV ranges: 10 V, 100 V
6.5 digits display range for OCV measurement
AC-IR ranges: 5 ranges from 5 mΩ to 50 Ω
5.5 digits display range for AC-IR measurement at 1 kHz
Smallest resolution: 10 nΩ (AC-IR) and 10 μV (OCV)

USPs

Referential adjustment accurately compensates for the effects of eddy currents by using actual batteries as a reference
Mutual Interference Reduction (MIR) enables stable, parallel inspection with two instruments positioned close to each other
Simultaneous ΩV measurement reduces measurement time by up to 50 %
Route Resistance Monitoring allows to reliably monitor test leads for predictive maintenance or troubleshooting

Applications

Incoming goods inspection of cells
Ageing process monitoring
EOL cell grading
Formation process monitoring

In detail:

Enhance your battery testing capabilities with the unmatched accuracy and speed of the HIOKI BT6065 Precision Battery Tester. Designed for high-capacity cells with low internal resistance, this compact 2-in-1 instrument delivers precise Open Circuit Voltage (OCV) and AC Internal Resistance (AC-IR) measurements at the industry-standard frequency of 1 kHz. Its 5 resistance ranges, spanning from 5 mΩ to 50 Ω, make it perfect for advanced cell grading and quality assurance in battery production. Featuring a 6.5-digit display, the BT6065 achieves a highly precise DC voltage resolution of 10 µV and an AC-IR resolution of 10 nΩ, combining the capabilities of two instruments into one compact unit.

In addition to its high measurement accuracy, the BT6065 Battery Tester offers four innovative features developed in collaboration with leading battery manufacturers. These features not only improve usability but also help to avoid typical issues that are known to arise in the battery testing process.

Referential Adjustment accurately compensates for the effects of eddy currents by using actual batteries as a reference, ensuring more reliable measurement results, especially when testing batteries in trays. Route Resistance Monitoring enables continuous detection of issues like probe wear and wire breaks to support predictive maintenance and prevent good cells from being misidentified as bad due to poor contacts or wiring. The Mutual Interference Reduction (MIR) function allows two instruments in close proximity to operate in parallel without interfering with each other. Finally, simultaneous AC-IR and OCV measurement reduces measurement time by up to 50%.

For time-efficient use in production environments, the BT6065 can be used with a multiplexer to increase measurement channels while maintaining its exceptional accuracy. The instrument provides all necessary interfaces for seamless integration, including LAN, RS232C, Ext. I/O, USB-C, and a temperature sensor terminal. Communication commands from the BT3562A model can be used without modification, allowing seamless upgrades of the battery tester in existing test systems.

BT6065 Precision Battery Tester
Power cord
Startup guide
Operating precautions

Related Products

L2100

L2100 - PIN TYPE LEAD

L2100 - Pin Type Lead The L2100 is a pin type lead designed for high voltage battery measurements with robust insulation and long reach for precise readings. Technical Details: Dimensions: A: 300 mm, B: 172 mm, L: 1400 mm Max voltage: 1000 V DC Compatibility: BT3562, BT3563, BT3564

€398.00*

View product

L2120

L2120 - Pin type lead

Pin type lead, A:300 mm, B:172 mm, L:1400 mm, for high Voltage Battery measurements, 1000 V DC max., for the BT60X5

€408.00*

View product

L2121

L2121 - CLIP TYPE LEAD
