HIOKI PW3335 - POWER METER
The PW3335 is a single channel Power Meter offers high-precision measurement of power consumption in various electrical devices and installations.
Description
Product information HIOKI PW3335 - POWER METER
The HIOKI PW3335 is a single channel Power Meter and offers high-precision measurement of power consumption in various electrical devices and installations. It is designed for standby power measurements and energy-saving assessments, with maximum input current ranges of 1 mA to 20 A. Featuring a 4 parameter, 7-segment numeric LED display and wide measurement bandwidth, this power meter provides reliable accuracy across a variety of applications. The compact design and intuitive interface make it suitable as a universal tool in any power electronics lab
Technical Information:
- Measurement range: Voltage 6V to 1000 V, Current 1 mA to 20 A
- single phase / two wires measurement
- Frequency measurement Range: DC, 0.1 Hz to 100 kHz
- Power accuracy: ±0.15% of reading
- Display: 4-parameter, 7-segment LED, 99.999 count
- Dimensions: 210 mm x 100 mm x 245 mm
- Weight: 3 kg
- Input Connectors: voltage, current
- Safety Category: CAT II 1000 V
What's in the Box
- PW3335
- Instruction manual
- power cord
- 2x voltage and current input terminal safety cover
- 4x safety cover installation screws (M3 × 6 mm)
