HIOKI 9772 PIN TYPE LEAD

HIOKI 9772 PIN TYPE LEAD

HIOKI 9772 pin type lead 1 8mm tip diameter

HIOKI 9772 PIN TYPE LEAD

HIOKI 9772 pin type lead 1 8mm tip diameter

€298.00

Content: 1 Each

Available in 21 days

€298.00

HIOKI 9772 PIN TYPE LEAD

Product number: 9772

GTIN/EAN: 4536036007721

Length: 1921 mm

Weight: 0.18 kg

Product information HIOKI 9772 PIN TYPE LEAD

The Hioki 9772 Pin-Type Lead is designed for use in narrow spaces where making contact with the subject of measurement is difficult, such as when maintaining emergency batteries. The lead features two parallel, spring contact tips with a diameter of 1.8 mm, allowing for stable connection with the measurement object. Its four-terminal structure ensures precise measurements in confined spaces.

Technical Details:

Parallel tips, spacing: 2.5 mm
Diameter singe tip: 1.8mm
Continuous current: AC/DC 2 A
Maximum rated voltage between terminal and ground: 60 V DC, 30 V AC RMS, 42.4 V AC peak
Operating temperature range: 0°C to 40°C
Storage temperature range: -10°C to 50°C
Length: approx. 1900 mm
Weight: approx. 180 g
Accessories: Instruction manual
Spare parts: 9772-90 tip pin

Related products

20

9772-90 - Tip pin

9772-90 - Tip pin

9772-90

9772-90 - Tip pin

The Hioki 9772-90 is the replacement measurement tip for the Hioki 9772 test lead. Technical Detail: Coaxial pin, diameter: 1.8 mm Contact surface: gilded

€38.40 €48.00

HIOKI RM3548 - Portable Resistance Meter
