L4933 - CONTACT PIN SET

€18.00*

Content: 1 Each

Prices excl. VAT plus shipping costs

In stock in Germany

Available stock: 20

Product details

Product number: L4933

EAN: 4536036000968

Weight: 0.02 kg

Product information L4933 - CONTACT PIN SET

The L4933 Test Probe Set is fully insulated except for the front part of the tip. It can be fitted to Hioki's L9207-30, L9208, L9170-10 and DT4911 test leads and is an optional accessory for many Hioki multimeters and current clamps.

Technical Details:

Max Voltage: 60V DC, 30V AC
Max Current: 3A
Length over all: 95mm
Tip length: 48mm
Tip diameter (isolated section): 1.3mm
Tip diameter (contact part): 1.0mm
Tip blank part: 3mm
Tip surface: gilded
Compatible Multimeters: 3030-10, DM7275, DM7276, DT4223, DT4224, CM4141, CM4371, CM4373, CM4375, DT4223, DT4224, DT4261, DT4281, DT4282
Compatible Clamp Meters: 3280-10F, 3280-70F, CM3281, CM3289, CM3291, CM4141, CM4371, CM4373, CM4375

L4933
